Inverter Experimental Trainer
Product Name : Industrial Product Line Training System with Robotic Manipulator
Model: LA-BSEL-I
Specification:
Output Characteristic
·Max Output Voltage : 230V
· Rating Output Frequency : Max 400Hz
· Rating Output Ampere : 4.8A
· Max Continuous Out Ampere : 5.4A
· Output Capacity : 2.1 kw
Power :
· Voltage & Frequency -3ǫ200/208/220V 50Hz -200/208/220/230V 60Hz
· Allowable Voltage Fluctuating : 10%
· Allowable Frequency Fluctuating : 10%
Control Characteristic
· Frequency Control Range : 0.1~400Hz
· Frequency set Resolving Power -Digital : 0.01~0.1Hz, Analogic : 0.06/60Hz
· Output Frequency Resolving Power : 0.01Hz
· Frequency Setting Signal : DC 0~10V, DC 4~20mA
· Accelerating & Decelerating Time : 0.1~6,000 Sec
· Control Characteristic : Sine Wave PWM Type
Protective Function
· Motor Protective : Protective Terms of Electronic Thermal
· Instantaneous Over Current : About 200%
· Over Voltage : Main Circuit DC Voltage About 400V
· Under Voltage : Main Circuit DC Voltage About 400V
· Instantaneous Electrostatic : 15m Sec Over Brake
· Over Load : Rating Out Ampere About 150%
Cubicle Bonding Machine
Digital Volt Meter : 1EA
· Digital Ampere Meter : 1EA
· Digital RPM Meter : 1EA
· Digital Watt Meter : 1EA
· MCCB(30AF, 10AT) : 1EA
· Induction Motor(750W) : 1EA
